LB8000-A30-FC-ST

Asymmetric 30° Beam Angle Free-Cut Static White LED Strip Light
  • Light Source: LED
  • CCT: 27K, 30K, 35K, 40K, 50K, 60K
  • CRI: 90+
  • LEDs/ft: 91
  • Cutting Length: Cuttable Anywhere
  • Width: 0.57 (14.4 mm)
  • Power W/Ft: 3.6
  • Voltage: 24
  • Lumens/Watt: 68
  • Max. Run: 16
  • IP: 54
  • Max Lumens: 250 lumens/ft
  • White: 250 lumens/ft

Dynamic Platforms and Technologies:

The Angled LED Strip Light features an optical system engineered to deliver controlled directional illumination. When installed, it provides a 30° asymmetrical beam angle, ensuring high visual uniformity while effectively reducing glare. Its low-profile triangular geometry enables clean integration into under-cabinet, millwork, and corner conditions, making it well suited for task lighting and accent applications in kitchens, wardrobes, shelving, display cases, and office environments. Designed as a robust, high-performance linear lighting solution for interior architectural applications, the strip light is offered in six CCT options ranging from 2700K to 6000K. It delivers continuous, smooth, dot-free illumination and is field-cuttable at any length due to its free-cut capability. Rated IP54 and IK04, it is suitable for use in demanding architectural environments.

Downloadable Files:

Spec Sheets

LB8000-A30-FC-ST High Performance
