DIMS TO WARM AVAILABLE PRODUCTS

Smart Dim is new technology that mimics traditional incandescent light when dimming. The use of Smart Dim allows you to make a smooth dimming transition from 3000K to 1800K, shifting into rich amber tones that encourage relaxation. It is ideal for hospitality and residential applications, and maintains high lumen output for the most stringent energy codes required by today’s legislation. Smart Dim comes paired with a high CRI of 90+ and superior lumen output of 95 lumens per watt. This game changing technology delivers rich, warm light to enhance each environment. With an option of 4 lumen outputs of 900, 1200, 1500, and 2000, you have the choice to manipulate different application requirements, while maintaining the beauty of traditional dimming.

DIMMING OPTIONS

DIM TO WARM WITH SMART DIM TECHNOLOGY can be supplied with a variety of dimming and control protocols 0‑10V. DMX, DALI, or Lutron EcoSystem and can be dimmed down to 1% of initial light output:

DIMTR (Triac & Electronic Low Voltage Dimming in 120V only) Triac & Electronic Low Voltage dimming driver available when ordered with the following options (DIMTR-120) and only available in 120V.

DIM10 (0‑10V 1% Dimming Standard) 0-10V driver which can be dimmed down to 1% of initial light output with a 0-10V dimmer when ordered with the following options (DIM10-120, DIM10-277).

LUTECO – Provided with Lutron EcoSystem driver. Compatible with Lutron GRAFIK Eye EcoSystem, Lutron Energi Saver node EcoSystem, or Lutron Quantum systems and Lutron Vive.  When ordered with the following options (LUTECO).

LUT2W– (Lutron® Hi-Lume A-Series 2-Wire Forward Phase Control 1% Dimming in 120V).  When ordered with the following options (LUT2W).

DMX – Compatible with Digital Multiplex Controller, Available with two options: DMX-512: Standard DMX Controller and DMX-RDM: DMX Controller with Remote Device Management.

DALI– Compatible with Digital Addressable Lighting Interface, available with two options: TD6 and TD8.
